JL-302-Dusk-to-Dawn-Photocell-Bulb-Socket
Rate voltage:
Enclosure Size:
Ø 70(2.8inch)dia.x 98(3.9inch)mm
Ø 41(1.6inch)dia.x 76(3.0inch)mm
Length:
Customizable

Ordering Information

*JL-302A- **

*:The Model Number

**:Enclosure Size

302A=Ø 70(2.8inch)dia.x 98(3.9inch)mm

303A=Ø 41(1.6inch)dia.x 76(3.0inch)mm

Product Summary

The Dusk to Dawn Photocell Socket for outside lights JL-302/302 series is applicable to control the Outdoor LED Lighting, Garden lighting, Passage Lighting and Doorway Lighting automatically in accordance with the ambient natural lighting level.

JL - 302/303 Dusk to Dawn Adapter electric apparatus has been approved by both UL companies in the United States UL and CUL column name, file number for E346727.


Technical Data

-Dusk to Dawn Photocell Bulb Socket-

dusk to dawn adapter.jpg


-Time Delay 30~120 seconds-

-Temperature Compensated-

-Convenient and easy to install-

-Works on any type of lamp-

-Improves security-

ModelJL-302AJL-302B
Rated Voltage100-120VAC, 50/60Hz200-240VAC, 50/60Hz
Rated Loading150W
Power Consumption1.5VA
On/Off Levels

10~20Lx On (Dusk);30~60Lx Off (Dawn)

Ambient Temperature-40℃ ~ +70℃
Related Humidity96%
Body Meas.98×Φ70mm(JL-302); 76×Φ41mm(JL-303)
Lamp cap & holderE26/E27





Installation

Disconnect power; Put the E26/27 Bulb Socket Sensor Control  screw on the standard socket.

Push the  Dusk till Dawn Sensor on and twist it clockwise to lock it into the Photocontrol Receptacle.

Adjust the Bulb Socket PhotoControl Receptacle position if necessary.


Initial Testing

It is normal for the SWITCH to take several minutes to turn off when first installed.

To test “turn on” during daytime, cover its eye with sliding the metal strip mounted.

Do not cover with finger because light traveling through fingers may be great enough to keep the switch open.

Test will take approximately 2 minutes.
